Chamberlain MIRACLE-ONE - SURGE SUPPRESSOR WIRING DIAGRAM

46
SURGE SUPPRESSOR WIRING DIAGRAM
Miracle 1 Second Miracle 1 Master
Miracle 1 Single
BLACK
MOTOR
WHITE RED
BRAKE
SINGLE OR MASTER ONLY SECOND ONLY
BROWN BLUE
LIMITS
GREEN BLACK
MOTOR
WHITE RED
BRAKE
BROWN BLUE
LIMITS
GREEN BURGLAR ALARM INPUT
UL SENSOR
123456 78 9101112 13141516
Green
Blue
Brown
Red
White
Black
1
2
3
4
5
6
1
2
3
4
5
6
Green
Blue
Brown
Red
White
Black
1
2
3
4
5
6
Green
Blue
Brown
Red
White
Black
7
8
9
10
11
12
13
14
Proximity Switch
Normally Open
Elite Part # A PRS
Refer to Page 31
Refer to Page 16
Refer to Page 17
7
8
9
10
11
12
13
14
Removable Terminal Connectors
Com
N.O.
Ground
For Toll Free Technical Support: 1-888-ELITE-10
