Chamberlain SL600 - INTRODUCTION; Product Specifications; Carton Inventory

6
Specifications
INTRODUCTION
Carton Inventory
Main AC Supply: 110-127Vac / 220-240Vac; 50/60Hz
Motor Voltage:
24 Vdc
Input Power:
100 W
Ambient Temperature Range:
-20 ~ +50 ˚C
Maximum Gate Weight:
600 Kg (Model SL600)
1000 Kg (Model SL1000)
Maximum Gate Width:
8 m
Maximum Pull Force (N):
780 (Model SL600)
970 (Model SL1000)
Protection Level: IP 44
Travel Speed:
22 cm/s
Daily Cycle Rate: Maximum 50 cycles per day
Gate Operator Weight:
6 Kg
Installation
Manual
(Not shown)
Remote Control, model TX4UNI (2)
M8x80 Expanding screw (4)
Mounting plate
Gate Operator
Release key (2)
M8 X40 Screw with
hexagon nut and plain
washer (4 sets)
Limit switch bracket (2)
