35
Your garage door opener is equipped with features to provide you with greater control over your
garage door operation.
Alert2Close
The Alert2Close feature providesa visual and an audible alertthat an unattended door is closing.
Timer-to-Close
The Timer-to-Close feature automatically closesthe door after a specified time period that can be
adjusted using the door control. Prior to the door closing there will be an audible and visual alert.
MyQ™
MyQ™ technology usesa 900MHz signal to provide two-way communication between the garage door
opener and MyQ™ enabled accessories. Your garage door opener is compatible with up to 8 MyQ™
accessories.
REMOTE CONTROLS AND DOOR CONTROLS (MyQ™)
Your garage door opener hasalreadybeen programmed at the factory to operate with your remote
control,which changeswith each use, randomly accessing over 100 billion new codes.Compatible with
MyQ™ enabled accessories, see page 47.
NOTE: Older Chamberlain remote controls, door controls,and third party products are not compatible.
MyQ
TM
Accessories
MEMORY CAPACITY
Remote Controls Up to 8
Door Controls Up to 2 MyQ™ door controls
Keyless Entries Up to 1
THE PROTECTOR SYSTEM
®
(SAFETY REVERSING SENSORS)
When properlyconnected and aligned,the safetyreversing sensors will detect an obstruction in the
path of the infrared beam.Ifan obstruction breaks the infrared beam while the door is closing,the door
will stop and reverse to full open position, and the opener lights will flash 10 times. Ifthe door is fully
open, and the safetyreversing sensorsare notinstalled, or are misaligned,the door will notclose from
a remote control. However, you can close the door if you hold the button on the door control or keyless
entry until the door is fullyclosed. The safetyreversing sensors do not effect the opening cycle.
ENERGY CONSERVATION
For energy efficiencythe garage door opener will enter sleep mode when the door is fully closed.The
sleep mode shuts the garage door opener down until activated.The sleep mode is sequenced with the
garage door opener lightbulb; as the lightbulb turns off the sensor LEDs will turn offand whenever the
garage door opener lights turn on the sensor LEDs will light. The garage door opener will not go into
the sleep mode until the garage door opener has completed 5 cycles upon power up.
LIGHTS
The garage door opener light bulbs will turn on when the opener is initially plugged in; power is
restored after interruption, or when the garage door opener isactivated. The lights will turn off
automatically after 4-1/2 minutes. An incandescent A19 lightbulb (100 watt maximum) or for maximum
energy efficiencya 26W (100W equivalent) compactfluorescentlight (CFL) bulb may be used.
Light Feature
The garage door opener is equipped with an added feature; the lights will turn on when someone
enters through the open garage door and the safetyreversing sensor infrared beamis broken. For
added control over the lightbulbs on your garage door opener, see page 37.
USING YOUR GARAGE DOOR OPENER
The garage door opener can be activated through a wall-mounted door control,remote control,
wirelesskeyless entryor MyQ™ accessory.
When the door is closed and the garage door opener is activated the door will open. Ifthe door senses
an obstruction or is interrupted while opening the door will stop. When the door is in any position other
than closed and the garage door opener is activated the door will close. If the garage door opener
sensesan obstruction while closing, the door will reverse.Ifthe obstruction interrupts the sensor beam
the garage door opener lights will blink 10 times.However,you can close the door if you hold the button
on the door control or keyless entryuntil the door is fully closed. The safetyreversing sensorsdo not
affectthe opening cycle.
The safetyreversing sensor must be connected and aligned correctly before the garage door opener
will move in the down direction.
BATTERY BACKUP
The batterybackup system allowsaccess in and outofyour garage, even when the power is out. When
the garage door opener is operating on batterypower, the garage door opener will run slower,the light
will not function,the BatteryStatus LED will glow solid orange,and a beep will sound approximately
every 2 seconds.
