BACK
DETERGENT
CYCLE TIMES DET PRIME
RA PRIME
RINSE AID
CONCENTRATION
CYCLE TIMES Sets the run times for the detergent pump
CONCENTRATION Sets detergent concentration in wash tank
RINSE AID Sets the rinse-aid pump run time
DET PRIME Press to prime Detergent pump
RA PRIME Press button to prime rinse-aid pump
BACK Returns to main settings screen above
LEGEND - Detergent/Rinse-aid Settings
Installation
PW = 7777
Cycle Times, Concentration, and Rinse Aid
Cycle Times -
Initial Fill: Sets time detergent pump
runs during machine fill.
Factory Default Initial Fill Setting:
Enter 4 for Sodium Hydroxide based detergent
Enter 30 for Potassium Carbonate based detergent
Prime: Sets the time detergent pump runs to prime detergent line when:
• machine is turned on for first time and line is initially charged or reset button is
pressed to clear an alarm.
• Factory Default Prime Setting: 30 sec.
Detergent Concentration -
Set Point: Sets required detergent concen-
tration in wash tank measured in millivolts.
Concentration: Actual value being measured
in the tank measured in millivolts.
Tank Temp: The detergent sensor will not add
detergent unless the tank temperature is greater
than 150°F and one complete wash cycle has run.
Factory Default Set Points:
Enter 300 for Sodium Hydroxide based detergent.
Enter 500 for Potassium Carbonate based detergent.
4
30
• Set Point and Concentration are relative values and not indicative of actual PPM or concen-
tration.
• For best results: Consult the chemical manufacturer's recommendation for concentration
and PPM.
• Perform a titration test to determine the proper concentration has been achieved.
The tank detergent sensor must
remain clean to ensure accurate
readings. Clean sensor with a
soft cloth each day.
NOTE: Press the button, enter "7777" and Enter on the keypad to access
cycle times, concentration, and rinse-aid. Prime buttons are not password
protected.
13
