DET
R /A
Program the Chemical Dispensing System
Rinse-aid
Detergent
SELECT CYCLE
READY
Touch to Change
WASH TEMP
Use the digital touchscreen display to enter operating settings. Refer to the instructions below
to set the system parameters.
Installation
1. Place pick-up tubes in full
containers.
2. Press power button on.
Button will illuminate and
machine will begin to fill.
3. Press 'TOOLS' to access
the main settings screen.
I/O Input and Output Screen
TEMPS Temperature monitoring screen
MAINT Maintenance Menu
DETERGENT Detergent & R/A settings
DELIME Forces machine into delime mode
SLEEP Idle time before sleep (PW protected)
MAIN Return to the main operating screen
LEGEND - Main Settings
OPTIONAL CHAMPION BUILT-IN DETERGENT
AND RINSE-AID DISPENSING SYSTEM
(IF EQUIPPED)
System Prep
Main Settings Screen
Password Protected Sleep -- PW = 7777
Press 99 and enter "7777" in keypad to access
setting.
Sets number of hours the machine must sit idle
before washand booster tank heaters turn off
to save energy.
Factory Default: 99 hours.
99
NOTE: The Cycle Times, Concentration, Rinse Aid and Sleep settings are PW protected.
The DET PRIME and RA PRIME are free access.
12
