The Express 250 Concrete
Mounting Template
The Express 250 is a DC fast charging station for electric vehicles. The default Express 250
installation requires service wiring to be installed underground and run to a concrete pad. (If a site
requires surface mounting, contact ChargePoint before beginning work, to obtain an approved
surface installation method.) The ChargePoint Express 250 Concrete Mounting Template (CPE250-
CMT) correctly aligns anchor bolts and conduit openings to ensure the Express 250 can be easily
installed and connected.
The CPE250-CMT, available from ChargePoint, includes:
• 16 mm (5/8 in)-11 thread, 305 mm (12 in) long threaded mounting bolts with plastic caps on one
end
• 16 mm (5/8 in) nuts
• 16 mm (5/8 in) washers
• Printed specification detailing how to position an assembled CPE250-CMT in the concrete
Note: You must order the CPE250-CMT separately, with sufficient lead time before the site
preparation. This kit is not included with the ChargePoint Express 250 charging station.
WARNING: Use of a ChargePoint approved mounting method, such as the CPE250-CMT, is
required for safe installation of the Express 250. Failure to use an approved mounting
method may result in a risk of tip-over, which can cause death, personal injury, or property
damage, and will void the Limited One-Year Parts Exchange Warranty.
