Install the CPE250-CMT
1. Trench and excavate an opening to accommodate the wiring conduit and the concrete
mounting pad that meets local codes and requirements, per site drawings.
2. Run conduit to each station as needed. If the stations will be Paired, run DC and Ethernet
conduit between stations as well.
3. Build the form and lay rebar for the foundation.
4. On the CPE250-CMT, locate the “FRONT” marking and the conduit guide fingers. Position the
conduit guide fingers facing up.
5. Place the assembled CPE250-CMT so that the “FRONT” marking aligns with the specified front
of the station.
6. Slide the CPE250-CMT over the conduit stub-ups until the top surface of the template is
positioned 50.8 mm (2 in) below where the top surface of the concrete will be when poured.
The surface of the concrete must align with the bottom of the plastic caps.
• Carefully press the CPE250-CMT down onto the conduit to avoid flexing it.
• Ensure the conduits are plumb.
• Use a level to check that the CPE250-CMT is level from front to back and from side to side.
7. Tie or shim the CPE250-CMT to the rebar to prevent movement during concrete pouring.
8. Pour the concrete.
Note: Make sure the concrete surface between the conduits is completely level and free of any
irregularities.
9. Complete the Construction Signoff Form provided by ChargePoint to verify that the site is
correctly completed and ready for product installation.
WARNING: Failure to install the ChargePoint® charging station in accordance with these
instructions and all local building practices, climate conditions, safety standards, and all
applicable codes and ordinances may lead to risk of death, injury, or property damage, and
will void the Limited One-Year Parts Exchange Warranty.
Important: It is critical that the conduits are positioned properly and plumb. The tolerance
where the conduits enter the station is 2 mm (1/16 in).
Important: Before pouring concrete, the CPE250-CMT and the conduit must be secured in
place to prevent them from rising or floating out of position while the concrete is poured
and curing.
