Key
Item Description
1 ANT1, ANT2 and
ANT3
Ports for attaching wireless antennas.
(Only in WiFi models).
2 WAN port RJ45 Ethernet port.
3 Factory Default
button
Lets you restore the appliance to its
factory defaults. The button is
recessed into the appliance chassis to
prevent accidental restoring of factory
default settings. For more information
on how to restore factory defaults, see
the
Check Point 600/700 Appliance
Administration Guide
.
4 PWR+12VDC Connects to the power supply's cable.
Note - The power cable must be
securely screwed in to the appliance.
5 Reboot button Lets you forcibly reboot the appliance.
The button is recessed into the
appliance chassis to prevent accidental
reboot. The app
press the button.
6 DMZ ports Ethernet ports:
• Left - RJ45
