1 LAN1-LAN12
ports
RJ45 Ethernet ports.
2 Ground (Earth) Functional grounding.
3 LAN13-LAN16 Serves as Power Sourcing Equipment
(PSE). Total power budget is 62W
maximum. By default, the PoE port
automatically provides power when a
compliant PD is connected. PoE
supports up to four standard 802.3af
devices or up to two standard 802.3at
devices. If two 802.3at devices are
plugged in, the remaining two ports of
PoE do not provide power and operate
like normal Ethernet ports.
