1. Product Overview
The SR209 chassis has been modified to support both tool-less 3.5” HDD carrier and PCIe 3.0 slot, and transformed to feature-
advanced SR209 Plus. Beneath the chassis, an information sticker reads revision and manufacturing code, necessary for technical
support.
Table 1 Chenbro SR209 Plus specifications
Feature
Description
MB Form Factor
 ATX (12” x 9.6")
Dimension
(Dx W x H)
 465.0 x 198.0 x 425.0 (mm)
 18.31” x 7.80” x 16.73” (w/o bezel)
Drive Bay
 3 x 5.25" External, 4 x 3.5" Hot-swap (Option), 4 x 3.5” Internal (Option)
Storage Backplane
 1 x 3.5" 4-port 12Gbps Mini-SAS HD Passive Backplane
 1 x 3.5" 4-port 12Gbps SAS/SATA Passive Backplane
PSU Form Factor
 PS/2 Single or N+1 Redundant
Indicator
 1 x Power Status, 2 x LAN Activity, 1 x HDD Status, 1 x System Alarm
Front Control
 1 x Power On/Off, 1 x System Reset, 1 x Alarm Mute, 2 x USB2.0/USB3.0 (Option)
Cooling Fan
 HDD Cage: 80 x 25 mm (1), PCI: 80 x 25 mm (1) (Option), Rear: 120 x 25 mm (1)
System Security
 Intrusion Switch, Key Lock, Kensington Slot
Expansion Slot Opening
 7 x Full Height (5 x Full Length + 2 x Half Length)
Net Weight
 7.8 kg/17.18 lb
Gross Weight
 9.8 kg/21.59 lb
Cubic Feet
 2.94
Container Loading
 20’: 350, 40’: 734, 40’H: 820
Slide Rail
 Supported
