NVF5 Series User Manual Chapter 6 Parameter Function Description
6.3.3 Accel./Decel. Time and Curve Setting
The acceleration time refers to the time required for the inverter to accelerate from
zero to F0.07-maximum output frequency；the deceleration time refers to the time
required for the inverter to decelerate from F0.07-maximum output frequency to zero.
 Linear Accel./Decel.
NVF5 has 4 groups Accel./Decel. time,you can switch them by using digital inputs.For
example：Configure DI1 and DI2 as switch terminals to consist 2 binary digits（1means DI
setting is effective，0 means DI setting is ineffective）
 S Curve Accel./Decel.
NVF5 has 2 groups S curve Accel./Decel. mode，you can select by setting parameter
F1.12：
S curve Accel./Decel.1：When the target frequency is fixed, the output frequency
increases or decreases according to the S curve. It can be used in places requiring slow
start or stop, such as conveyor belts, etc.
S curve Accel./Decel.2：When the target frequency is dynamically changed in real
time, the output frequency will increase or decrease in real time according to the S curve.
It is suitable for occasions with high comfort and fast real-time response.
Code Name Default
Setting
Range
Description
F5.01
DI1 Function
Selection
28
0 ～ 63
28：
Accel. Time Selection
Terminal1
F5.02
DI2 Function
Selection
29
0 ～ 63
29：
Accel. Time Selection
Terminal 2
K2 K1
Accel./Decel. Time
Curve
0 0
Group1：F0.14、F0.15
0 1
Group2：F8.04、F8.05
1 0
Group3：F8.06、F8.07
1 1
Group4：F8.08、F8.09
Code Name Default Setting Range Description
F0.14 Accel. Time 1
Depend
on Series
（0.0 ～ 6500.0）s
-
F0.15 Decel.Time 1
Depend
on Series
（0.0 ～ 6500.0）s
-
F8.04 Accel. Time 2
Depend
on Series
（0.0 ～ 6500.0）s
-
F8.05 Decel.Time 2
Depend
on Series
（0.0 ～ 6500.0）s
-
F8.06 Accel. Time 3 Depend
（0.0 ～ 6500.0）s
-
- 61 -
