CHINT NVF5 Series User Manual

NVF5 Series User Manual Chapter 6 Parameter Function Description
on Series
F8.07 Decel.Time 3
Depend
on Series
（0.0 ～ 6500.0）s
-
F8.08 Accel. Time 4
Depend
on Series
（0.0 ～ 6500.0）s
-
F8.09 Decel.Time 4
Depend
on Series
（0.0 ～ 6500.0）s
-
F1.12
Accel./Decel.
Mode
Selection
0
0 ～ 2
0：Linear
Acceleration
1：S Curve
Acceleration1
2：
S Curve
Acceleration2
F1.13
S-curve
Scale of
Starting Time
30.0%
（0.0 ～ 100.0）%
-
F1.14
S-curve
Scale of
Stopping
Time
30.0%
（0.0 ～ 100.0）%
-
6.4 Motor Auto Tuning
Motor auto tuning is a process which the inverter analyse motor parameters . The
auto tuning methods include static auto tuning and rotate auto tuning .
Code
Name
Default
Setting Range
Description
F2.22
Motor Auto
Tuning
0
0 ～ 2
0：No Operation
1：Static Tune
2：Rotate Tune
F2.00 Motor Type 0
0 ～ 2
0：AC Induction
Motor
1：Reserve
2：Reserve
F2.01
Motor NP
Power
Depend on
motor type
（0.1 ～ 1000.0）kW
-
F2.02
Motor NP
Voltage
Depend on
motor type
0 ～ Inverter Rated
Voltage
-
F2.03
Motor NP
Current
Depend on
motor type
（0.01～ 1000.00）A
-
F2.04
Motor NP
Frequency
Depend on
motor type
0.01 ～ F0.07
-
F2.05 Motor Poles
Depend on
motor type
2 ～ 24
-
- 62 -
