NVF5 Series User Manual Chapter 6 Parameter Function Description
Chapter 6 Parameter Function Description
6.1 Start Source Setting
Command control is used to control inverter start、stop、run forward、run reverse、
jog.
There are 4 types of command control:Integral Keypad、Terminal、Comm.、Remote
Keypad，Command reference channel can be selected by parameter F0.01.
Code
Name
Default
Setting Range
Description
F0.01
Speed Reference
Channel Selection
0
0
Integral
Keypad
1
Terminal
2
Comm.
3
Remote
Keypad
6.1.1 Integral Keypad Command
Setting parameter F0.01=0，Press RUN、STOP key to run or stop inverter.Press RUN
key，RUN indicator light；In Run mode，Press STOP key to stop inverter，RUN indicator
light off.
6.1.2 Terminal Command
Setting parameter F0.01=1，Start and Stop inverter by DI terminals.Setting parameter
F5.08 select DI terminals control mode.There are four types of DI terminals control
mode,Two Wire Control Mode1、Two Wire Control Mode 2、Three Wire Control Mode 1、
Three Wire Control Mode 2。
Code Name Default
Setting
Range
Description
F5.08
Terminal
Control Mode
0
0
Two Wire Control
Mode1
1
Two Wire Control
Mode 2
2
Three Wire Control
Mode 1
3
Three Wire Control
Mode 2
Users can select DI1 ～ DI4 and HDI as DI terminals command channel by setting
parameters F5.01 ～ F5.05 to select DI1 ～ DI4 and HDI function.
 Two Wire Control Mode1：
As shown in the following figure，When K1 is closed，the inverter will run forward；
When K2 is closed，the inverter will run reverse；When K1、K2 is closed or opened at the
- 38 -
