Chore-Tronics® 3 Breeder Edition Control Control Setup
MT2484A
13
Mechanical Scale
1.In the Setup/Digital Inputs/Type & numbers Screen put a Check mark in the Mechanical Scale box.
2.Select the Mechanical Scale button.
3.From the drop-downs select the Board and Input.
4.The Status column shows if the switch is activated or not.
5.See Wiring Chore-Tronics Control and Weigh-matic Scale for wiring information.
