Chore-Time Tronics 3 User Manual

Wiring Chore-Tronics® 3 Breeder Edition Control 32
MT2484A
BinTrac to Chore-Tronics Control Wiring
Wiring
CT3 Control
Red Black White Green
Set I2I Board Dip Switches to one address higher than the last IO addressed used
Set LCC Board Dip Switches all to "Off"
SJB (Scale Junction Box
BinTrac HouseLink HL-10P
ON
123 42
Bin S1 S2 S3 S4
DOnOnOffOff
Bin S1 S2 S3 S4
A Off Off Off Off
Bin S1 S2 S3 S4
BOnOffOffOff
ON
123 42
Bin S1 S2 S3 S4
C Off On Off Off
ON
123 42
ON
123 42
Bin-Trac Dip Switch Settings
24 Volt Supply
(55309)
