Milliohm Meter 16502 User’s Manual
2-2
2.4 Measurement Time
Begin from measuring, analog sampling, calculation to binning or compare signal output
measurement time. Please refer to the Table 2-1.
Item
Fast
Medium
Slow
Measurement time
65 mS
150mS
650 mS
Table 2-1 Measurement Time
2.5 Temp. Measurement/Correction Spec.
Measurement Range
Measurement Accuracy
(PT100 temperature probe
excluded)
Correction Accuracy
resistance measurement
accuracy need to be added)
-10.0 °C ∼ 39.9°C
(-14.0 ∼ 103.8°F)
±0.3% of the reading
±0.5°C (0.9°F)
±0.3%
40.0 ∼ 99.9°C
(104 ∼ 211.8°F)
±0.3% of the reading
±1.0°C (1.8°F)
±0.6%
Note
1. Temperature measurement fuction need to cooperate with optional function
interface and probe for operating.
2. It is necessary to plus the tolerance of probe as temperature measuring (the
type of PT100 temperature probe is < ±0.5°C).
2.6 Others
• Power: (1) 90V ∼ 125V AC 50Hz/60Hz. Power consumption is 80VA.
(2) 190V ∼ 250V AC 50Hz/60Hz. Power consumption is 80VA.
• Environment: Operating -- 10°C to 40°C, 10 to 90% relative humidity
Storage -- 0°C to 50°C, 10 to 90% relative humidity
• Dimension: 320(W) x 115(H) x 350(D) (Foot pad and terminals are not included)
• Weight: Approximately 5.5 Kg
