Chroma 16502 - GPIB Command Structure

Descriptions of GPIB Interface (Commands Same as RS232 Interface)
5-3
5.2.6 Port Driver
The specification of port driver is listed below:
DIO1-8
SRQ
NRFD
NDAC
Open Collector
EOI
REN
DAV
IFC
ATN
3 States
5.2.7 Response of Interface Message
Interface Message
Meaning
Response
GTL Go To Local
Be able to switch the instrument to
Local state
SDC
Selective Device Clear
Clear GPIB interface state
IFC
Interface Clear
Reset GPIB interface
5.3 GPIB Commands Description (IEEE 488.2)
5.3.1 Command Structure
Command
Parameter
Return
ABORt
[No query]
CALCulate
: ALARm
: CONDition
FAIL | PASS
FAIL | PASS
: MODE
PULSe | CONTinuous
PULS | CONT
:BINNing
: CLEAr
[No query]
: RESUlt?
[For query only]
<NR1>
: MATH
: NAME
DEV|PCNT
DEV|PCNT
: BIN{1|2|3|4|5|6|7|8}
: UPPer
<NRf+> {Suffix Unit}
<NR2> Suffix Unit
: LOWer
<NRf+> {Suffix Unit}
<NR2> Suffix Unit
: NOMInal
<NRf+> {Suffix Unit}
<NR2> Suffix Unit
: STATe
<Boolean>
<NR1>
: COMPare
