Chroma 16502 - Memory Management

Milliohm Meter 16502 User’s Manual
4-6
The default setting is 19200.
CORREC.TEMP
It sets the specified temperature value t0 (°C) that you want to convert in temperature
correction function. The default setting is +20.0°C.
THERM.COEFF
It sets the coefficient αt0 in temperature correction function. The default setting is
3930 ppm.
TEMP .PROBE
It sets the type of probe for measuring temperature. There are two types of PT100 and
PT500. The default setting is PT100.
AUTO REPORT
It sets if measurement data and result are sent by RS232 interface automatically but
trigger mode is invalid when it is set to internal trigger (INT). The factory default setting is
OFF. The sent formats of each measurement function when the setting ON are as the
following: (the data in bracket ([]) only exist when the function is activated)
<MEAS. DISPLAY> : Rx[,Compare Result][,Binning Result][, AMBIENT TEMP. ]
<TEMP CONV. MEAS.>:Rx,T, [,AMBIENT TEMP.]
<R SCAN TEST> : [R1,R1 Result][,R2.,R2 Result][,R3,R3 Result], R, R Result,Total
PASS/FAIL[,AMBIENT TEMP.] PS: The data won’t be sent when R1~R3 doesn’t execute
the test.
COMP. DISP.:
It sets compare test result of displaying high/low limit, two options of do not show test
result (OFF) and show test result (ON). The factory default value is not showing test result
(OFF).
PADR OFFSET
The pad bias offset of contact end as measuring the instrument, the setting range -50.0mΩ
~ +50.0 mΩ. The factory default value is +0.0 mΩ.
4.3.2 Memory Manage
In SYSTEM SETUP, press [F2] (i.e. MEMORY MANAGE) it will show the following screen:
< S Y S T E M S E T U P >
C A L B R A T I O N
M
E M
M
A N
A
G E
S Y S T E M C O N F I G
← Enter System Calibration Screen
F2
← Enter Memory Manage Screen
F3
← Set the System Parameter
F4
F1
Enter the correct password to access the Memory Manage function as below shown.
