Chroma 16502 - Page 79

R SCAN Function
9-5
R SCAN Connection Diagram
Pin list:
Handler interface of 16502
(Connector A)
D-sub 9 pin of R scanner
test fixture (Connector B)
Handler 24 pin of ATS
(Connector C)
P01
/EXT
-
-
P01
/EXT
P04,P24
RESERVE
-
-
P24
RESERVE
P05
GND
P08
GND
P05
GND
P06
GND
-
-
P06
GND
P07
GND
-
-
P07
GND
P08
COMMON
P01
COMMON
P08
COMMON
P09,P13
RESERVE
-
-
P13
RESERVE
P10
VEXT
-
-
P10
VEXT
P11
VINT
P02
VINT
P11
VINT
P15
Total Fail
-
-
P15
Total Fail
P18
/EOT
-
-
P18
/EOT
P21
PASS,BIN3,Total PASS
-
-
P21
Total PASS
P22
/ACQ
-
-
P22
/ACQ
P14
BIN5,H2
P03
N1
-
-
P16
BIN6,H3
P04
N2
-
-
P17
BIN1,L3
P05
P1
-
-
P19
BIN2,L4
P06
P2
-
-
P23
BIN2,L4
P07
ENABLE
-
-
