Electrical Safety Analyzer 19032-P Quick Start Guide
Limit Value Setting
HI - LIMIT 0.1 ~ 510.0mΩ
Offset Range
0 ~ 500.0mΩ
Test Time(Note 6) 0.3 ~ 999 sec. Continue
Secure Protection Function
Ground Fault
Interrupt
Leakage Current
(for WVAC only)
AC:0.25mA~0.75mA, ON/OFF selectable
H.V Floating
Output
Front panel H.V output only
Fast Discharge Approx. 0.2S (Discharge Voltage 5.1kV)
Panel Operation
Lock
YES, with password On/Off
Floating Output(Note 7)
Function Wac, Wdc, IR
Leakage Current Less than 3.5mAac or dc
Memory Storage
Memories, Steps
100 groups of memory, each memory includes
max.50 Steps (TOTAL 500 steps)
PASS/FAIL Judgment Window
Indication, Alarm
PASS: (Short Sound)
FAIL: W-Arc, W-Hi, W-Lo, IR-Lo, IR-Hi, GR-Hi ,
GR-Lo, GFI, GBVO (Long Sound)
40A
8A
3A
Current
510m
100m
10m
Resistance
4
