Electrical Safety Analyzer 19032-P Quick Start Guide
5
Remote Connector
Rear Panel
9-Pins connector:
START, RESET, UNDER TEST, PASS, FAIL
Start/Reset Control TTL Low Level Active, minimum 20mS
RS232 Interface
Baud rate 300 ∼ 19200, data bits: 8. stop bit: 1
USB The programming language is SCPI.
Ambient Temperature and Relative Humidity
Specifications
range
18 to 28°C (64 to 82°F), 20 to 70% RH.
Operable range 0 to 40°C (32 to 104°F), 20 to 80% RH.
Storage range
-10 to 50°C (14°C to 122°F), ≤ 80% RH.
Power Requirement(Note 8)
Line Input 90Vac ~ 250Vac , 50 or 60 Hz
Power Consumption
No load: < 100W, Rated load:1000W,
Maximum load:1200W
Dimension 430 W x 133 H x 500 D mm
Weight
<24 kg
Ground Bond Floating
Rear Panel Output Only
HV Output
(Fixed port 3)
HV output can set to HV, Low or Off.
Maximum Voltage is 5kVac, 6kVdc
Maximum Current is 100mA ac or peak dc
Wac maximum add 10 counts extra error
Wdc maximum add 2 counts extra error
Ground Bound Output
(Floating Ground)
Ground Bound can set to Close or Open
(Floating Voltage 1000Vrms or 1400Vpeak ac
maximum)
Ground Bond Close, the maximum current is
40Amp.
Maximum add a 2mΩ extra error.
Note
1. Twin Port ON for 50mAac, 6mAdc maximum.
Twin Port ON for less than 1/2 duty cycle output only.
Less than 1/2 duty cycle of 120sec when output power is
greater than 300VA.
