Electrical Safety Analyzer 19032-P Quick Start Guide
6
The current resolution is 1.2count for WAC, and 1.6count for
WDC calculated value.
2. The minimum testing time arrives at 90% output voltage
specification(NO load).
3. Design in Specifications. Validation point is 1.25kV with a
250kΩ resistor.
4. 10GΩ~50GΩ without scan unit only.
5. Twin Port ON for 40Amps output maximum.
Twin Port ON for less than 1/2 duty cycle output only.
GB Scanner output add extra 2mΩ error.
For reaching optimal accuracy, please use the standard
four-wires type for measuring.
When offset lower than 10mΩ, it is over test specification.
By using offset can add extra 5mΩ error.
6. The minimum testing time arrives at 90% output current
specification(NO load).
7. Except TWIN-PORT ON, GFI ON/OFF, Scanner installed.
8. Except GB-F 4kV option, Scanner installed.
