High Power DC Electronic Load 63200 Series Operation & Programming Manual
SPECIFICATION
Model 63201 63202 63203
Power*1 260W 2600W 260W 2600W 520W 5200W
Current 0-30A 0-300A 0-5A 0-50A 0-60A 0-600A
Voltage 1-80V 2.5-500V 1-80V
Min. operating voltage 1V @ 30A 1V @ 300A 2.5V @ 5A 2.5V @ 50A 1V @ 60A 1V @ 600A
Constant Current mode
Range 0-30A 0-300A 0-5A 0-50A 0-60A 0-600A
Resolution 7.5mA 75mA 1.25mA 12.5mA 15mA 150mA
Accuracy 0.1%+0.1%FS 0.2%+0.1%FS 0.1%+0.1%FS 0.2%+0.1%FS 0.1%+0.1%FS 0.2%+0.1%FS
Constant Resistance mode
Range 0.005-20ohm 0.25-1000ohm 0.25-1000ohm 10-40000ohm 0.0025-10ohm 0.125-500ohm
Resolution 12 bits 12 bits 12 bits 12 bits 12 bits 12 bits
Accuracy*2 0.6mho+0.35% 0.9mho+0.1% 0.012mho+0.35% 0.04mho+0.1%
1.2mho+0.35%
*4
1.2mho+0.1%
Accuracy*3 (Vin>7V) 0.6mho+0.35% 0.012mho+0.35% 0.012mho+0.35% 112.5u mho+0.35% 1.2mho+0.35% 0.024mho+0.35%
Constant Voltage mode
Range 1-16V 1-80V 2.5-125V 2.5-500V 1-16V 1-80V
Resolution 4mV 20mV 31mV 125mV 4mV 20mV
Accuracy 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS
Constant Power mode
Range 0.6-260W 6-2600W 0.625-260W 6.25-2600W 1.2-520W 12-5200W
Resolution 7.5mW 75mW 3.125mW 31.25mW 22.5mW 225mW
Accuracy 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS
Dynamic mode
Timing
T1&T2 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S
Resolution 1uS 1mS 1uS 1mS 1uS 1mS
Accuracy 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm
Slew rate 5mA-1.25A/uS 50mA-12.5A/uS 0.8mA-0.2A/uS 8mA-2A/uS 10mA-2.5A/uS 100mA-25A/uS
Resolution 5mA/uS 50mA/uS 0.8mA/uS 8mA/uS 10mA/uS 100mA/uS
Current
Range 0-30A 0-300A 0-5A 0-50A 0-60A 0-600A
Resolution 7.5mA 75mA 1.25mA 12.5mA 15mA 150mA
Accuracy 0.4%FS 0.4%FS 0.4%FS
Measurement
Voltage read back
Range 0-16V 0-80V 0-125V 0-500V 0-16V 0-80V
Resolution 15 bits 15 bits 15 bits 15 bits 15 bits 15 bits
Accuracy 0.05%+0.05%FS 0.05%+0.05%FS 0.05%+0.05%FS
1-4
