General Information
Current read back
Range 0-30A 0-300A 0-5A 0-50A 0-60A 0-600A
Resolution 15 bits 15 bits 15 bits 15 bits 15 bits 15 bits
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS 0.1%+0.1%FS
Power read back
Range 0-260W 0-2600W 0-260W 0-2600W 0-520W 0-5200W
Resolution 15 bits 15 bits 15 bits 15 bits 15 bits 15 bits
Accuracy 0.3%+0.3%FS 0.3%+0.3%FS 0.3%+0.3%FS
General
Short circuit
Current 30A 300A 5A 50A 60A 600A
SIZE (mm) 440(W) X 177(H) X 644(D) 440(W) X 177(H) X 644(D) 440(W) X 353(H) X 644(D)
WEIGHT 35Kg 35Kg 58Kg
EMC & Safety CE CE CE
*Specifications are subject to change without notice.
1. The power rating specifications at ambient temperature = 25°C and see the diagram below for power derating.
Power Rating
100%
77%
°C
Ambient Temperature
10°C 20°C 30°C 40°C
2. The Vin must be greater than min. operating voltage of each model.
3. The Vin must be greater than 7V of each model.
All CR mode accuracy should be referring to the CC mode accuracy.
4. Setting error will be 1% for R < 0.005Ω at CRL range.
