High Power DC Electronic Load 63200 Series Operation & Programming Manual
Model 63204 63205 63206
Power*1 520W 5200W 650W 6500W 1040W 10400W
Current 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Voltage 2.5-500V 1-80V 1-80V
Min. operating voltage 2.5V @ 10A 2.5V @ 100A 1V @ 18A 1V @ 180A 1V @ 60A 1V @ 600A
Constant Current mode
Range 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Resolution 2.5mA 25mA 4.5mA 45mA 15mA 150mA
Accuracy 0.1%+0.1%FS 0.2%+0.1%FS 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS
Constant Resistance mode
Range 0.125-500ohm 5-20000ohm 0.008-32ohm 0.4-1600ohm 0.0025-10ohm 0.125-500ohm
Resolution 12 bits 12 bits 12 bits 12 bits 12 bits 12 bits
Accuracy*2 0.024mho+0.35% 0.08mho+0.1% 0.375mho+0.35% 0.75mho+0.1%
1.2mho+0.35%
*4
1.2mho+0.1%
Accuracy*3 (Vin>7V) 0.024mho+0.35% 225u mho+0.35% 0.375mho+0.35% 0.075mho+0.35% 1.2mho+0.35% 0.024mho+0.35%
Constant Voltage mode
Range 2.5-125V 2.5-500V 1-16V 1-80V 1-16V 1-80V
Resolution 31mV 125mV 4mV 20mV 4mV 20mV
Accuracy 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS
Constant Power mode
Range 1.25-520W 12.5-5200W 0.36-650W 3.6-6500W 1.2-1040W 12-10400W
Resolution 6.25mW 62.5mW 4.6mW 46mW 22.5mW 225mW
Accuracy 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS
Dynamic mode
Timing
T1&T2 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S
Resolution 1uS 1mS 1uS 1mS 1uS 1mS
Accuracy 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm
Slew rate 1.6mA-0.4A/uS 16mA-4A/uS 3mA-0.75A/uS 30mA-7.5A/uS 12mA-3A/uS 100mA-25A/uS
Resolution 1.6mA/uS 16mA/uS 3mA/uS 30mA/uS 12mA/uS 100mA/uS
Current
Range 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Resolution 2.5mA 25mA 4.68mA 46.8mA 15mA 150mA
Accuracy 0.4%FS 0.4%FS 0.4%FS
Measurement
Voltage read back
Range 0-125V 0-500V 0-16V 0-80V 0-16V 0-80V
Resolution 15 bits 15 bits 15 bits 15 bits 15 bits 15 bits
Accuracy 0.05%+0.05%FS 0.05%+0.05%FS 0.05%+0.05%FS
1-6
