High Power DC Electronic Load 63200 Series Operation & Programming Manual
Model 63210
Power*1 1450W 14500W
Current 0-15A 0-150A
Voltage 2.5-500V
Min. operating voltage 2.5V @ 15A 2.5V @ 150A
Constant Current mode
Range 0-15A 0-150A
Resolution 3.75mA 37.5mA
Accuracy 0.1%+0.1%FS 0.2%+0.1%FS
Constant Resistance mode
Range 0.083-333ohm 3.3-13200ohm
Resolution 12 bits 12 bits
Accuracy*2 0.036mho+0.35% 0.092mho+0.1%
Accuracy*3 (Vin>7V) 0.036mho+0.35% 337.5u mho+0.35%
Constant Voltage mode
Range 2.5-125V 2.5-500V
Resolution 31mV 125mV
Accuracy 0.05%+0.1%FS 0.05%+0.1%FS
Constant Power mode
Range 5-1450W 50-14500W
Resolution 25mW 250mW
Accuracy 0.5%+0.5%FS 0.5%+0.5%FS
Dynamic mode
Timing
T1&T2 0.025-10mS 1mS-30S
Resolution 1uS 1mS
Accuracy 1uS+100ppm 1mS+100ppm
Slew rate 3mA-0.75A/uS 25mA-6A/uS
Resolution 3mA/uS 25mA/uS
Current
Range 0-15A 0-150A
Resolution 3.75mA 37.5mA
Accuracy 0.4%FS
Measurement
Voltage read back
Range 0-125V 0-500V
Resolution 15 bits 15 bits
Accuracy 0.05%+0.05%FS
