Installation
2m
3. Testing
Detection Scope
2m
4m
6m 8m0m
0m
2m
110°
It is recommended to mount it at the height of 2m from the ground. (For installation
notices, please see page 21-22)
1. Choose installation place
Fix the installation bracket on the wall with screws, and then fit the groove at the back
of the detector on the bracket.
Press the test button on the back of the detector, walk in the detection scope and watch
the LED indication to make sure the detector is working.
2. Fix the detector
Adjust the bracket angle to achieve the best detection effect.
4. Adjust the bracket angle
Top view
Side view
Ground
Side view
Top view
Note: If pet-immune function is used, please do not adjust the angle up or down, but keep it
parallel with the wall.
