CIAT Connect 2 User Manual

19
No.
Description
Setting
Default
Display conditions
INPUTS (CONTINUED)
1
418
Check of manual HP1 pressure switch input
Open/Closed
1
419
Check of stage 1, circuit 1 fault input
Open/Closed
1
420
Check of stage 2, circuit 1 fault input
Open/Closed
If P4 = 2
1
422
Check of manual HP2 pressure switch input
Open/Closed
If P3 = 2
1
423
Check of stage 1, circuit 2 fault input
Open/Closed
If P3 = 2
1
424
Check of stage 2, circuit 2 fault input
Open/Closed
If P5 = 2
1
425
Check of fault input for circuit 1 electronic
expansion valve
Open/Closed
If P42 = ALCO
1
426
Check of fault input for circuit 2 electronic
expansion valve
Open/Closed
If P42 = ALCO
OUTPUTS
1
430
Pump 1 control state
On/Off
1
431
Pump 2 control state
On/Off
If (P2 = 1) or P25 = 2
1
432
State of circuit 1 Y/C control output
On/Off
If P2 = 3
1
433
State of circuit 2 Y/C control output
On/Off
If P2 = 3 and P3 = 2
1
435
State of heat trace cable control output
On/Off
If P2 ≠ 1 (water-to-water)
1
436
State of heater control output
On/Off
If P2 ≠ 1 (water-to-water)
1
437
State of recovery heat trace cable control output
On/Off
If P2 ≠ 1 (water-to-water) and P29.1 = Yes
1
438
State of maximum power output
On/Off
If P111 = Max. power
1
439
State of boiler output
On/Off
If P111 = Boiler
1
440
State of cooling/heating output
On/Off
If P111 = Cooling/Heating
1
441
State of HP control output, stage 1, circuit 1
On/Off if P21 = without
High Temperature mode/Low Noise mode/Off if
P191 = acoustic
If P21 = without, P2 = 2, 3
1
442
State of HP control output, stage 2, circuit 1
On/Off
If P180 = 2 and P3 = 1, P2 = 2, 3
1
443
State of HP control output, stage 1, circuit 2
On/Off
If P180 = 1 and P3 = 2, P2 = 2, 3
1
444
State of HP control output, stage 2, circuit 2
On/Off
If P180 = 2 and P3 = 2, P2 = 2, 3
1
445
State of HP control output, stage 3, circuit 1
or
State of HP control output, common stage 1
On/Off
If P180 = 3 and P3 = 2
P11 = split P2 = 2, 3 or If P180 = 3 and
P3 = 2 P11 = mixed
1
446
State of HP control output, stage 3, circuit 2
or
State of HP control output, common stage 3
On/Off
If P180 = 3 and P3 = 2
P11 = split P2 = 2, 3 or If P180 = 3 and
P3 = 2, P11 = mixed
1
447
Driving voltage, stage 1, HP control
0-10 V
If P21 = 2 or 3 and P11 = Intertwined
1
448
Driving voltage, stage 1, circuit 1, HP control
0-10 V
If P21 = 2 or 3 and P11 = split or mixed
1
449
Driving voltage, stage 1, circuit 2, HP control
0-10 V
If P21 = 2 or 3 and P11 = split or mixed
1
450
Driving voltage, common stage 1, HP control
0-10 V
If P21 = 2 or 3 and P11 = Mixed
1
451
State of circuit 1 balance valve output
On/Off
If P12 = Yes
1
452
State of circuit 2 balance valve output
On/Off
If P12 = Yes
1
530
State of electric stage 1
On/Off
If P22 = Yes
1
531
State of electric stage 2
On/Off
If P22 = Yes
1
532
State of electric stage 3
On/Off
If P22 = Yes
1
533
State of electric stage 4
On/Off
If P22 = Yes and P112 = 4
1
535
Air blade percentage information
0-100%
If P20 =Yes and P10 = Centrifugal
1
555
CPU version number
1
556
Console version number
*
1
557
Version number of circuit 2 board
If P3 = 2
1
558
Version number of changeover board
If P2 = reversible air-to-water
1
559
Version number of auxiliary heater board
If P22 = Yes
1
560
Version number of circuit 1 expansion valve
XX.YY VCM XX.YY
If P42 = CIAT and P3 = 1
1
561
Version number of circuit 2 expansion valve
XX.YY VCM XX.YY
If P42 = CIAT and P3 = 2
1
570
"SO" order number"
To be entered via a PC
1
571
MO number
To be entered via a PC
1
572
Machine identification name
To be entered via a PC
1
573
Machine identification number
To be entered via a PC
