Control mode:
Water loop winter protection:
Return and supply control:
Stage differential:
Interstage differential:
Proportional coefficient:
Integral coefficient:
Derivative coefficient:
Time coefficient:
Control with compensation:
Storage control:
P 1 4 1 R E G U L A T I O N T Y P E
O N I N L E T
P 1 4 1 R E G U L A T I O N T Y P E
O N O U T L E T
P 1 4 1 R E G U L A T I O N T Y P E
ON O U T L E T + C O M P E N S A T I O N
P 1 4 2 W A T E R L O O P W I N T E R
P R O T E C T I O N Y E S
P 1 4 2 W A T E R L O O P W I N T E R
P R O T E C T I O N N O
P 1 4 3 S T A G E
D I F F E R E N T I A L x . x K
P 1 4 4 I N T E R S T A G E
D I F F E R E N T I A L x . x K
P 1 4 5 P . C O E F F I C I E N T
x . x
P 1 4 6 I . C O E F F I C I E N T
x . x
P 1 4 7 D . C O E F F I C I E N T
x . x
P 1 4 8 T . C O E F F I C I E N T
x x x s
P 1 5 0 C O M P E N S A T I O N
C O E F F I C I E N T x . x
P 1 5 1 C O M P E N S A T I O N
T I M E x x x s
P 1 5 4 S T O R A G E
C O N T R O L Y E S
P 1 5 4 S T O R A G E
C O N T R O L N O
Water supply control
with compensation
by water return
