40
LED test: used to turn on the console LEDs corresponding to the machine configuration:
Control setpoint:
Outdoor air temperature:
Water inlet temperature in heat exchanger on circuit 1:
Water outlet temperature in heat exchanger on circuit 1:
Hot water temperature at condenser inlet (water-to-water unit):
Hot water temperature at condenser outlet (water-to-water unit):
Circuit 1 coil temperature:
Circuit 1 coil temperature where P14 = 1:
Refrigerant temperature on circuit 1 heat exchanger:
Water temperature measured on manifold (case of two heat exchangers):
Water outlet temperature on circuit 2 heat exchanger:
Circuit 2 coil temperature:
P 2 5 1 C O N T R O L
S E T P O I N T x x . x °
P 2 5 2 O U T D O O R A I R
T E M P E R A T U R E x x . x °
P 2 5 5 E X C H . 1 W A T E R
I N L E T T E M P . x x . x °
P 2 5 6 E X C H . 1 W A T E R
O U T L E T T E M P . x x . x °
P 2 5 7 W A T E R T E M P E R A T U R E
C O N D E N S E R I N L E T x x . x °
P 2 5 8 W A T E R T E M P E R A T U R E
C O N D E N S E R O U T L E T x x . x °
P 2 5 9 C I R C . 1 C O I L T E M P .
A:- x x . x ° B : - x x . x °
C:- x x . x ° D : - x x . x °
P 2 5 9 C I R C . 1 C O I L T E M P .
- x x . x °
P 2 6 0 E X C H . 1
R E F R . T E M P . - x x . x °
P 2 6 1 M A N I F O L D W A T E R
O U T L E T T E M P . - x x . x °
P 2 6 2 E X C H . 2 W A T E R
O U T L E T T E M P . - x x . x °
P 2 6 3 C I R C . 2 C O I L T E M P .
A:- x x . x ° B : - x x . x °
C:- x x . x ° D : - x x . x °
