49
Control contact for fan stages P180 = 3 (3 stages) and P3 = 2 (2 circuits) and P11 = split
P441, P442, P443 and P444 same as P180 = 2 (2 stages) and P3 = 2 (2 circuits):
Control contact for fan stages P180 = 3 (3 stages) and P3 = 2 (2 circuits) and P11 = mixed
P441, P442, P443 and P444 same as P180 = 2 (2 stages) and P3 = 2 (2 circuits):
Speed control information (intertwined coil):
Speed control information (split or mixed coil), stage 1, circuit 1:
Speed control information (split or mixed coil), stage 1, circuit 2:
Speed control information (mixed coil), common stage 1:
Circuit 1 balance valve output contact:
Circuit 2 balance valve output contact:
Electric stage output:
Air blade information:
Version:
P 4 4 5 H P C O N T R O L
S T A G E 3 C 1 O U T P U T O N
P 4 4 6 H P C O N T R O L
S T A G E 3 C 2 O U T P U T O N
P 4 4 5 H P C O N T R O L
C O M S T A G E 1 O U T P U T O N
P 4 4 6 H P C O N T R O L
C O M S T A G E 3 O U T P U T O N
P 4 4 7 H P S T A G E 1
D R I V I N G V O L T A G E X X . X V
P 4 4 8 H P S T A G E 1 C 1
D R I V I N G V O L T A G E X X . X V
P 4 4 9 H P S T A G E 1 C 2
D R I V I N G V O L T A G E X X . X V
P 4 5 0 H P C O M S T A G E 1
D R I V I N G V O L T A G E X X . X V
P 4 5 1 C 1 B A L A N C E V A L V E
O U T P U T O N
P 4 5 2 C 2 B A L A N C E V A L V E
O U T P U T O N
P 5 3 x E L E C T R I C S T A G E x
O U T P U T O N
P 5 3 5 A I R B L A D E
O P E N I N G % x x x %
P 5 5 5 C P U V E R S I O N N O .
xx- x x
P 5 5 6 C O N S O L E V E R S I O N
N O . xx- x x
P 5 5 7 C I R C U I T 2 B O A R D
V E R S I O N N O . xx- x x
P 5 5 8 R E V E R S A L B O A R D
V E R S I O N N O . xx- x x
