Transmig 210, 250, 310, 330
Page 8 of 31 DOC No: MIGTRN0001
Date: 14/09/98 Issue No: 2
2. SPECIFICATIONS
2.1 Transmig 210 and Transmig 250 Specifications
Transmig 210 Transmig 250
Compact Remote Compact Remote
Plant Assembly part number
704830 704831 704833 704834
Plant Mass 77Kg 107Kg 78Kg 108Kg
Plant Dimensions 860mm x 490mm x 845mm 860mm x 490mm x 845mm
Power Source part number
704832 704808 704835 704809
Power Source Mass 60Kg 58.5Kg 61Kg 59.5Kg
Power Source Dimensions 640 x 310 x 732 640 x 310 x 732
Number of Phases Single Phase Single Phase
Frequency 50 / 60 Hz 50 / 60 Hz
Open Circuit Voltage Range 18.9 to 34.2V 19 to 43V
Output Current Range 25 to 210A 30 to 250A
Rated Output for 15A Outlet at 240V
210A @ 25%
148A @ 50%
105A @ 100%
184A @ 25%
130A @ 50%
92A @ 100%
µRated Output for 20A Outlet at 240V
210A @ 36%
164A @ 60%
127A @ 100%
¾
ÙRated Output for 25A Outlet at 240V
¾
250A @ 25%
180A @ 50%
127A @ 100%
Duty Cycle Period 5 minutes or 10 minutes 5 minutes or 10 minutes
Number of Output Voltage Values 16 16
Wire Size Range 0.6 - 0.9 Hard / 0.9 - 1.2 Soft 0.6 - 0.9 Hard / 0.9 - 1.2 Soft
Operating Temperature Range 0°C to 40°C 0°C to 40°C
Primary input voltage 200V 220V 240V 200V 220V 240V
ÑRated Input Current (output of 127A)
25A 23A 21A 30A 27A 25A
Rated kVA (output of 127A)
5kVA 5kVA 5kVA 6kVA 6kVA 6kVA
Maximum Input Current 42A 38A 35A 52A 47A 43A
Generator Requirements 8.5kVA 8.5kVA 8.5kVA 10kVA 10kVA 10kVA
Rated Outlet @ Max Duty Cycle 25A 23A 20A 30A 27A 25A
ªFuse Size @ Max Duty Cycle 50A 50A 40A 60A 60A 50A
Ñ The Rated Input Current should be used for the determination of cable size & supply
requirements.
ªMotor start fuses or motor start thermal circuit breakers are recommended for this application.
Australian Standard AS3000 (Clause 2.4.3.4) permits the use of a fuse or circuit breaker rated at
two times the rated input current.
µTo achieve this rating, the 15 Amp plug and primary supply lead (as supplied) must be replaced
with a 20 Amp plug & lead. This must be carried out by a qualified electrical tradesperson.
