0-5492 6-13 STICK (MMAW) Welding
Description Possible Cause Remedy
6 Non-metallic particles are trapped in
the weld metal (slag inclusion)
A Non-metallic particles may
be trapped in undercut from
previous run
A If bad undercut is present,
clean slag out and cover
with a run from a smaller
diameter electrode
B Joint preparation too
restricted
B Allow for adequate
penetration and room for
cleaning out the slag
C Irregular deposits allow slag
to be trapped
C If very bad, chip or grind
out irregularities
D Lack of penetration with slag
trapped beneath weld bead
D Use smaller electrode with
sufficient current to give
adequate penetration. Use
suitable tools to remove all
slag from corners
E Rust or mill scale is
preventing full fusion
E Clean joint before welding
F Wrong electrode for position
in which welding is done
F Use electrodes designed for
position in which welding
is done, otherwise proper
control of slag is difficult
Not cleaned,
or incorrect
electrode
Slag
trapped in
undercut
Slag trapped in root
