4.2.1. Initialization
During the initialization, the converter control system checks the presence of all internal
components and the embedded PC loads the operating system.
No voltage is present at the DC link and the IGBTs PWMs are completely stopped.
The transition from Initialization state brings the converter to the Standby state as long as the
emergency stop is deactivated (equipment armed).
4.2.2. Standby
The Standby state keeps the converter in low power mode until an Enable signal is received.
While the converter is in standby only the internal power supplies are energized. In particular,
