Analog inputs
The RMS magnitude set point will come from the (X17) connector (1 input for all three phases).
10V (input)  20Arms (output) (EL15 case)
4.3.3. Constant Power (CP)
This mode allows the user to define the active power consumption per output phase.
Parameters and limits
In CP mode, the user may modify the value of the following parameters, as long as they are
within the specified range:
Parameter
Allowed range of values
Active power (P)
[0 , +Maximum permitted depending on catalogue]
4.3.4. Constant Voltage (CV)
In CV mode, B2C works as a DC power supply.
Parameter
Allowed range of values
Unipolar voltage
[0 , +750]
Bipolar voltage
[-350 , +350]
4.4. Connection modes
As it has been previously mentioned, for the EL there are two possible connection modes:
- Independent phases: each phase (U,V,W) is controlled independently.
- Parallel phases: It is exactly the same as the previous case, but in this case the user has
shorted the phases. In this case the total amount of current consumed will be the sum
of all three phases.
- Unipolar mode: Electronic Load behaves as 3 independent and positive DC power
supplies.
- Bipolar mode: Electronic Load behaves as 2 independent DC power supplies. One is
positive and the other negative.
Please remember to disconnect the equipment before modifying the connection
mode.
