 (X8) Phase output terminal W.
 (X9) Neutral output terminal N.
 (X20) Negative output terminal U.
 (X21) Negative output terminal V.
 (X22) Negative output terminal W.
 (X10) Earth connection terminal for EUT ( ).
 (X11) DB9 connector for RS485 communications.
 (X12) Terminals for external Emergency Power Off (EPO) button.
 (X13) DB9 connector for CAN communications (input).
 (X14) DB9 connector for CAN communications (output).
 (X15) RJ45 connector for MODBUS interface.
 (X16) DE15 connector for digital inputs and outputs.
 (X17) DE15 connector for analogic inputs and outputs.
3.3. Equipment reception
3.3.1. Unpacking and checking the content
On receiving the device, make sure that the converter has not suffered any damage during the
transportation. Otherwise, make all pertinent claims to the supplier or to CINERGIA.
The packing of the device consists of a wooden palette, a cardboard or wooden packaging
(depending on the case), expanded polystyrene corner pieces, a polyethylene sleeve and bands;
all recyclable materials. Therefore, they should be disposed of according to current regulations.
We recommend to keep the packaging in case its use is necessary in the future.
In order to unpack, cut the bands and remove the cardboard packaging with a vertical
movement. In case of wooden packaging, remove it with the appropriate tools. Afterwards,
remove the corner pieces and the plastic sleeve. At this point the equipment will be unpacked
on the pallet. Please, use suitable tools to lower the converter from the pallet.
After unpacking the equipment, check that the data in the nameplate (stuck on the inner part
of the front door) correspond to those specified in the purchase order. Contact the supplier or
CINERGIA in case of disconformity.
Keep the equipment in the original package if it will not be used in order to protect it from any
possible mechanical damages, dust, dirt, etc…
3.3.2. Storage
The equipment shall be stored in a dry, ventilated place and protected against rain, water jets
or chemical agents. It is advisable to keep the converter into its original package, which has been
designed to assure the maximum protection during the transport and storage.
Do not store the unit where the ambient temperature exceeds 40ºC or falls
below -20ºC
