Cino eC - Machine Programming; Accessing and Exiting Programming; Programming Parameter Categories

09.
programming
access the programming
mode
quit the programming
mode
09.01. “progr”
09.01.a. key 1
…
key 8/10
09.01.b. prices
09.01.c. happy price
09.01.d. coins
09.01.e. temperatures
09.01.f. miscellaneous
09.01.g. diagnostics
09.01.h. sales audit
09.01.i. MDB
the vending machine is programmed by means of parameters
considered standard for the specific configuration required; values
forming the composition of recipes – written in the board memories
– enable the user to dispense drinks without requiring the installer
to set up special programmes; to modify these parameters to adapt
the drinks you have produced, refer to the following; at the end of
the chapter (see 09.07.), a summary table may help the user trace
back all the programming items;
to access the programming mode, open the front door of the
machine and use the service key in the safety switch;
attention
the vending machine is supplied and running to all effects in this
mode of operation; act extremely carefully;
press the “PROG” key (see 05.15.);
the display shows alternatively the messages:
- “1” to access the programming mode of machine variables;
- “2” to display the drink quantities you have dispensed;
- “3” to dispense on a free basis;
- “4” to dispense water to wash the water circuits;
- “5” to schedule maintenance operations;
after having programmed, press “1” and then the key “PROG” to go
back to the usual operation of the vending machine and to store all
changes you have made; the display will show:
press the key “PROG”, press “1”; the buttons of the selection
keyboard will assume the following functions:
the items are (scroll by means of key “1”):
contains the variable composing selection 1;
…
contains the variables composing selection 8/10;
to establish the prices of every single dispensing cycle;
to establish the prices of every single dispensing
cycle produced in
special time bands;
to determine the values of coins;
to set up the pressure boiler or boiler water temperatures;
to programme different options;
to display some machine parameters;
to display the quantity of dispensing cycles you have performed;
it contains the programming of the MDB protocol parameters;
Key 1
to scroll the items forward
Key 6
to scroll the items backward
Key 2
to scroll the variables of items forward
Key 3
to scroll the variables of items backward
Key 4
to increase the value of the variable on the screen
Key 5
to decrease the value of the variable on the screen
1= PROGRAMMING
3= FREE VEND
2= DATA 4= CLEAN
5= MAINTENANCE
END PROGRAMMING
wait ………
1= PROG.
PROGRAMMING
BUTTON N
PROGRAMMING
PRICES
PROGRAMMING
HAPPY PRICE
PROGRAMMING
TEMPERATURE
PROGRAMMING
COINS
PROGRAMMING
MISCELLANEOUS
DIAGNOSTICS
SALES AUDIT
PROGRAMMING
MDB
cino eC by
MAN1010105 rel. 03 dated 12.02.2014 page no. 27 of 50 page
