Chapter 2: Jumpers and Connectors
2.5.9 DVI_I1：DVI-I Connector
Pin Definition Pin Definition
1 DVI_TX2- 16 DVI Hot Plug Detect
2 DVI_TX2+ 17 DVI_TX0-
3 GND 18 DVI_TX0+
4NC19 GND
5NC20 NC
6 DDC_CLOCK 21 NC
7 DDC_DATA 22 GND
8 VGA VSYNC 23 DVI_TXCLK+
9 DVI_TX1- 24 DVI_TXCLK-
10 DVI_TX1+ C1 VGA_RED
11 GND C2 VGA_GREEN
12 NC C3 VGA_BLUE
13 NC C4 VGA_HSYNC
14 +5V C5 GND
15 GND
2.5.8 COM3、COM4：Voltage Select
PIN 1-3, PIN 2-4 5V
PIN 3-5, PIN 4-6 12V
PIN 7-9, PIN 8-10 RI (Default)
