DA-1000 User’s Manual
16
Chapter 1: Product Introductions
Front Panel
Power On/Off Switch
Press to power-on or power-off the system
AT/ATX Mode Select Switch
Used to select AT or ATX power mode
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Remote Power Terminal Block
Used to plug a remote power on/off switch with
terminal block
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
LAN Port 1 & 2
Used to connect the system to a local area network
Mic-in
Used to connect a microphone
Line-out
Used to connect a speaker
1.3 System I/O
