Cinzone DA-1000 - LINE_OUT1: Line-Out Jack (Green)

DA-1000 User’s Manual
30
Chapter 2: Jumpers and Connectors
2.5.13 LINE_OUT1：
Line-out Jack (Green)
Connector Type：5-pin Phone Jack
Pin Definition
1GND
2OUT_R
3NC
4GND
5OUT_L
2.5.14 MIC1：
Microphone Jack (Pink)
Connector Type：5-pin Phone Jack
Pin Definition
1GND
2MIC_R
3NC
4GND
5MIC_L
2.5.15 SATA1：SATA Connector
Pin Definition Pin Definition
1GND 12GND
2TX+ 13GND
3TX- 14+5V
4 GND 15 +5V
5RX- 16+5V
6RX+ 17GND
7GND 18GND
8 +3.3V 19 GND
9 +3.3V 20 +12V
10 +3.3V 21 +12V
11 GND 22 +12V
