Chapter 3: System Setup
3.2 Removing the Chassis
1. Loosen the 3 screws (left picture) and remove HDD base plate. Loosen the 5
screws (right picture) as marked on photo and place them aside.
2. Hold front and rear panel and lift up the body of unit vertically.
3. Turn over the body of the unit and place it gently.
