Cinzone DA-1000 - 3.1 Removing the Chassis Bottom Cover

DA-1000 User’s Manual
33
Chapter 3: System Setup
1. Turn over the unit to have the bottom side face up, loosen the 4 screws of bottom
cover and place them aside.
3.1 Removing the Chassis Bottom Cover
In order to prevent electric shock or system damage, before
removing the chassis cover, must turn off power and disconnect
the unit from power source.
WARNING
2. Remove the cover from the chassis.
