CipherLab 8000 Series Reference Manual

16 8000 Series Reference Manual
Bluetooth Specification
Frequency Range:
2.4 GHz
Data Rate:
433 kbps
Connected Devices:
1 for DUN mode
Up to 7 for SPP or PAN mode (AP required)
Profiles:
SPP, PAN, DUN
Coverage:
Class 1 – 250 meters line-of-sight
Max. Output Power:
Class 1 – 16 mW
Spread Spectrum:
FHSS
Modulation:
GFSK
Standard:
Bluetooth version 1.1
IEEE 802.11b/g
Model 8071 can easily connect to legacy networks through access points (APs). Roaming
among different networks is possible.
IEEE 802.11b/g is an industrial standard for Wireless Local Area Networking (WLAN),
which enables wireless communications over a long distance.
The speed of connection between two wireless devices will vary with range and signal
quality. To maintain a reliable connection, the data rate of the 802.11b/g system will
automatically fallback as range increases or signal quality decreases.
802.11b/g Specification
Frequency Range:
2.4 GHz
Data Rate:
802.11b – 1, 2, 5.5, 11 Mbps
802.11g – 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Connected Devices:
1 for ad-hoc mode (No AP)
Multiple for infrastructure mode (AP required)
Profiles:
IP/TCP/UDP
Coverage:
350 meters line-of-sight
Max. Output Power:
50 mW (802.11b)
Spread Spectrum:
DSSS
Modulation:
802.11b – DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (5.5 & 11 Mbps)
802.11g – OFDM
Standard:
IEEE 802.11b/g, interoperable with Wi-Fi devices

CipherLab 8000 Series Specifications

General

Humidity	5% to 95% non-condensing
Communication	Infrared
Barcode Scanner	Laser
Connectivity	Infrared
Storage Temperature	-20°C to 60°C
Keypad	21 keys (numeric / functional)
