CipherLab 8000 Series Reference Manual

Chapter 4 Configuration 67
Settings
Interface
Cradle-IR (Serial IR) Proceed to configure baud rate settings on your computer and the
mobile computer.
IrDA Point to the target IrDA device.
Bluetooth Approach the target Bluetooth enabled device.
Baud Rate
115200 (bps) Supported on CipherLab software, including download utilities.
76800 (bps) N/A
57600 (bps) Supported on CipherLab software, including download utilities.
38400 (bps) Supported on CipherLab software, including download utilities.
19200 (bps) Supported on CipherLab software, including download utilities.
9600 (bps) Supported on CipherLab software, including download utilities.
4800 (bps) N/A
2400 (bps) N/A
Note: If you select to use Serial IR of the Modem Cradle, any value other than 57600 bps
(default) must be configured through the DIP switch on the IR control board.
Load Program via Bluetooth
1. Go to System Menu > 7. Bluetooth Menu > 3. Security, and configure the following Bluetooth
settings first.
 Authentication
 PIN code
2. Go to System Menu > 6. Load Program and select Bluetooth.
3. Start the pairing procedure from your computer, for example, click [Pair Device] and/or
[Connect Bluetooth Serial Port].
4. Run any of the download utilities: ProgLoad.exe or Download.exe
- Select interface RS-232/IrDA for using Bluetooth SPP.
- Select COM port properties that match with the serial port settings used on your
computer.
Note: Only Model 8061 supports Bluetooth.

CipherLab 8000 Series Specifications

General

Humidity	5% to 95% non-condensing
Communication	Infrared
Barcode Scanner	Laser
Connectivity	Infrared
Storage Temperature	-20°C to 60°C
Keypad	21 keys (numeric / functional)
