Quick Start
USE CHARGING & COMMUNICATION CRADLE
The Charging & Communication Cradle charges your mobile computer and a spare battery
at the same time, and it could also be used for data communication.
ENCR Model
CCCR Model
Note: The Charging & Communication Cradle is equipped with either one USB Port (CCCR Model)
or one RJ45 Connector (ENCR Model).
Spare Battery Compartment
USB Port
RJ45 Connector
(Ethernet Function)
DC Jack Connector
(for power adapter connection)
DC Jack Connector
(for power adapter connection)
Spare Battery Compartment
Main Charging Station
(Mobile Computer Compartment)
Spare Battery Compartment
LED Indicator
