4.2 STATUS LED BAR ERROR SEQUENCES
The Wallbox eHOME is capable to detect the following operating errors:
- Ventilation required error
- Pilot error
- Proximity error
- Negative PWM error
- Maximum output current MiniDips error
- Temperature error
Whatever the error case is, the unit will stop charging and technical assistance will be
required, except from the temperature error. In this last case, the unit starts charging
when the operating temperature is reached again.
In the following sections it will be explained how the Wallbox eHOME shows the above
mentioned errors and the actions taken by the unit.
• Once the cable is disconnected
from the EV, the LED status bar
turns back into green (A status)*.
• In this status, the unit is available
to start a new charging process,
whenever it is required.
