9.4 WALL FIXATION PROCEDURE
9.4.1 NEEDED MATERIAL
Below, it is shown the list of materials (not included) that are necessary to fix the unit on
the wall:
MATERIAL
Qty
DIMENSIONS
Wall plug
3
Ø 6mm
Screws
3
3x45mm
All materials shown in the above table may vary
depending on the wall surface type.
9.4.2 CONSIDERATIONS
• The unit is designed to drain the water properly from
the upper side down.
• The charging point must be installed vertically (use a
level tool to ensure its installation at an angle of 90º)
• Please ensure that the installation surface is flat.
