4.2.3 PROXIMITY ERROR
4.2.4 NEGATIVE PWM VOLTAGE ERROR
• When the unit is connected to the
EV, a Proximity short-circuit to earth
may occur.
• Then, the status LED bar turns into
red and flashes in a sequence of
three blinks.
• When the unit is connected to the
EV, the PWM signal, used to
communicate the unit with the EV,
can be negative.
• Then, the status LED bar turns into
red and flashes in a sequence of
four blinks.
