Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
9.3.1 USING THE REAR CABLE INSERTION OPENING
Use a hammer and a flathead screwdriver carefully in order to break out the cable insertion
opening, as shown in the picture below.
Do not make any other holes on the enclosure. Use
only the marked cable insertion openings to install
the required electric pipes.
Install always double membrane seals to ensure IP
protection of the charging point.
Be careful of not damaging any of the inside
components when breaking out the rear cable
insertion opening.
