14 TECHNICAL DATA
Wallbox eHOME
AC INPUT
AC Power supply
1P + N + PE
AC Voltage
230V
AC
+/- 10%
Nominal input current
16 A / 32 A*
Nominal input power
3,7 kW / 7,4 kW*
Frequency
50 / 60 Hz
OUTPUT
Charge system
Mode 3
Sockets/ Plugs
Type 1 / Type 2 tethered cable*
Cable length
5m
Lock system
No
Maximum output power
3,7 kW / 7,4 kW*
Maximum output current
16 A / 32 A*
Output voltage range
230V
AC
(1P + N + PE)
GENERAL
Enclosure rating
IP54 / IK10
Enclosure material
ABS-PCV0
Operating temperature
-5ºC to +50ºC
Operating humidity
To 95% RH Non-condensing
Net weight
4Kg
OPTIONAL FEATURES
Extended operating temperature
(Optional Heater) -30ºC…+50ºC
eHOME BeON*
PRODUCT SPECIFICATION
Type Current Transformer
Ring Core
Material
Polyester
Dimensions
30 x 15 mm
Rated Insulation Level
0.72 / 3 /- kV
Connection
2S1 (-) / 2S2 (+)
Relation
16 / 0.05 A, 20 / 0.05 A, 25 / 0.05 A, 30 / 0.05 A, 35 / 0.05 A,
40 / 0.05 A, 45 / 0.05 A, 50 / 0.05 A, 63 / 0.05 A
Accuracy
Class I
Maximum cable length
200 m
Cable cross-section
1 mm²
* Depending on the model
